Wall Mounted Gas Detector
Created with Pixso. NH3 Ammonia Wall Mounted Gas Detector with High Sensitivity Sensor
  • name
  • name
  • name
  • name
  • name
  • name
  • name

NH3 Ammonia Wall Mounted Gas Detector with High Sensitivity Sensor

MOQ: 1PC
Detail Information
Product Description
Detail Information
Document:
Product Brochure PDF
Model NO.:
K500
Trademark:
KELISAIKE Or OEM
Origin:
Nanjing, China
HS Code:
90200000
Supply Ability:
1000sets Per Month
Type:
Metal Detector
Usage:
Metal, Gas
Installation Mode:
Wall Mounted
Application:
Industry
Transport Package:
Carton
Specification:
160*126*78mm
Customization:
Available | Customized Request
Stock:
1PC
Highlight:

High Sensitivity Imported Sensors Wall Mounted Gas Detector

,

Exd II CT6 Explosion Proof Gas Leak Detector

,

4-20mA Output Analog Industrial Gas Detector

Product Description
NH3 Ammonia Wall Mounted Gas Detector with High Sensitivity Sensor
The K500 wall mounted gas detector is engineered for continuous monitoring of hazardous gases in industrial environments. It operates independently with on-site audible and visual alarms, or can be integrated with central control systems via standard 4-20mA analog output.
Featuring high-performance imported sensors, the detector delivers stable signal transmission and reliable detection accuracy. The flameproof enclosure with Exd II CT6 rating ensures safe operation in explosive atmospheres including oil & gas facilities, chemical plants, and mining areas.
With flexible power supply options (220V AC or 24V DC) and programmable alarm thresholds, the K500 series is ideal for integration into DCS systems and industrial safety projects requiring long-term monitoring.
NH3 Ammonia Wall Mounted Gas Detector with High Sensitivity Sensor 0
Key Features
  • High sensitivity world famous imported sensors
  • Bright, red flashing visible alarm and loud 90dB audible alarm
  • Waterproof and dust-proof design for harsh environments
  • Compatible with DCS (Distributed Control System)
  • Flameproof body design according to IEC61508
  • Programmable alarm operation values with low/high level alarm indication
  • 220V AC or 24V DC power supply with 4-20mA analog output
  • Color screen 2+2 digits LCD display showing real-time gas concentration
  • Comprehensive self-test: sensors, lithium battery, circuit integrity, and alarm functions
  • Includes operator's manual, detection probe, calibration hose, USB cable, charger, and conversion plug
  • Certifications: CMC, Ex, MA (Safety Certificate of Approval for Coal Mining Products in China)
Product Specifications
ItemSpecification
Model NO.K500 gas leak detector
SensorsHigh sensitivity imported sensors
Sensor service life2-5 years
Operating voltage220V AC/24V DC
Display4 digital LED display
Alarm buzzer90db
Alarm modeAcousto optic alarm
Ambient temperature-20°C ~ +50°C / -50°C ~ +50°C
Relative humidity15~90%RH (non condensation)
MaterialAluminum alloy and stainless steel
Detecting methodDiffusion
Dimension(mm)160(L)*126(W)*78(H)mm
Explosion-proof gradeExdII CT6
WeightK500-D: 3.5kg, K500-N: 3.0kg
PackageCarton
Pcs/ctn1pc/ctn
Ctn size260x230x140mm
Payment termsT/T
Warranty1 year
Product Images
NH3 Ammonia Wall Mounted Gas Detector with High Sensitivity Sensor 1 NH3 Ammonia Wall Mounted Gas Detector with High Sensitivity Sensor 2 NH3 Ammonia Wall Mounted Gas Detector with High Sensitivity Sensor 3
